ASTM A479 UNS S31254 Compression Elbow manufacturer in India
The 6Mo Tube Fittings are constructed from a super austenitic stainless steel with a high nitrogen and molybdenum content. The excellent resistance to pitting and crevice corrosion of these fittings is well known. Furthermore, they have greater strength than standard austenitic stainless steel grades, such as SS 316L.
316L stainless steel Alloy 6Mo Compression Fittings are especially popular due to their superior resistance to stress corrosion cracking, which enables cold forming of tubes. Because they are extremely appropriate for usage in halide-containing conditions, they are typically encountered in marine equipment. These fittings can also be used in hydrochloric and sulfuric acid conditions. As a result, they are used in valves, pipes, and plumbing.
Buy 6 Mo Tube Fittings at reasonable rates from the stockholder.
Oil and gas, food processing, desalination, air pollution control, and chemical processing all make substantial use of the 6MO Stainless Steel Instrumentation Tube Fittings. The DIN 1.4529 Instrumentation Fittings are a cost-effective and technically appropriate alternative to nickel-based alloys, especially for applications requiring resistance to seawater corrosion. Because of its resistance to chloride ion-related stress corrosion cracking, the UNS N08926 6mo Compression Nut is widely utilised in marine and offshore industries.
Table of content
- 6Mo Tube Fittings Specification
- Types of DIN 1.4529 Instrumentation Tube Fittings
- AL-6XN Ferrule Fittings chemical composition
- UNS N08367 Tube To Tube Union mechanical composition
- UNS N08926 6mo Compression Nut equivalent grade
- Size chart of DIN 1.4529 Instrumentation Fittings
- 6Mo Compression Tube Fittings Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
Stainless steel Alloy 6Mo Compression Fittings
6 Mo Tube Fittings
DIN 1.4529 Instrumentation Fittings
6Mo Compression Tube Fittings
1.4529 6mo Ferrule Fittings
6mo Steel Double Ferrule Fittings
| Si | C | Mn | Cu | S | P | Ni | Cr | Mo | N |
|---|---|---|---|---|---|---|---|---|---|
| 0.7 | <0.02 | 1 | 0.75 | 0.01 | 0.03 | 18 | 20 | 6.1 | 0.2 |
Find the perfect fit with our diverse DIN 1.4529 Instrumentation Fittings dimensions and sizes
| Temper | Annealed | |
|---|---|---|
| Tensile Rm | 675 | MPa (min) |
| Tensile Rm | 98 | ksi (min) |
| R.p. 0.2% Yield | 310 | MPa (min) |
| R.p. 0.2% Yield | 45 | ksi (min) |
| Elongation (2” or 4D gl) |
35 | % (min) |
| title | Werkstoff | UNS |
|---|---|---|
| 6Mo | 1.4547 | S31254 |
We have a wide range of 6Mo Compression Tube Fittings available, ensuring that we can fulfill the needs of both instrumentation and industrial applications.
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
Learn about the refractive index and transparency properties of our 1.4529 6mo Ferrule Fittings for specialized applications.
Application of 6Mo Compression Tube Fittings
- Food processing equipment
- Beverage industry
- Pharmaceutical equipment
- Chemical processing
- Petrochemical industry
Packaging of DIN 1.4529 Instrumentation Fittings
Safeguard delicate items with plastic or paper sleeves when bundling them for shipment. Wooden crates are sturdy and reliable packaging solutions for transporting goods securely. Cardboard boxes are versatile and eco-friendly options for organizing your items during transit.
Frequently asked questions
How does the mechanical strength of DIN 1.4529 Instrumentation Tube Fittings compare to other stainless steels?
DIN 1.4529 Instrumentation Tube Fittings exhibit higher mechanical strength than traditional stainless steels, providing enhanced structural integrity in demanding applications.
Can AL-6XN Ferrule Fittings be used in sulfuric acid environments?
Yes, AL-6XN Ferrule Fittings demonstrate excellent resistance to sulfuric acid, making them suitable for applications in chemical processing plants and acid production facilities.
Are UNS N08367 Tube To Tube Union compatible with welding processes?
Yes, UNS N08367 Tube To Tube Union can be easily welded using common techniques, enabling efficient fabrication and installation.
What is the temperature range for UNS N08926 6mo Compression Nut?
UNS N08926 6mo Compression Nut can operate in a wide temperature range, typically from cryogenic temperatures up to 300°C (572°F), making them suitable for both low-temperature and high-temperature applications.
What are the advantages of using Stainless steel Alloy 6Mo Compression Fittings in seawater applications?
Are duplex compression fittings suitable for international export?
Yes, duplex compression fittings are commonly exported internationally due to their high demand and wide range of applications in various industries.
