We are dedicated to being the premier UNS N08020 bulkhead union manufacturer in India
Fit-lok is a well-known manufacturer of Alloy 20 Compression Tube Fittings as well as a variety of other piping-related products and components. Because of their versatility and effectiveness in a variety of setups, compression tube fittings are in high demand. To fulfil the needs of its customers, the company manufactures these fittings out of various metals and alloys, offering both customised and non-customized choices.
Fit-lok prefers Alloy 20 for the production of Compression Tube Fittings. This alloy comprises nickel, iron, and chromium, which provides good acid resistance and the ability to function well in a variety of environmental situations. Alloy 20 is especially well-suited for high-temperature applications.
We offer UNS N08020 hydraulic fittings at the most competitive rates in the Indian market
Fit-lok provides Alloy 20 Compression Tube Fittings to a wide range of industrial applications, including oil and gas, gas processing, food processing, petrochemical, chemical, power generation, sugar, and fertiliser industries. Alloy 20’s outstanding qualities ensure that these fittings work successfully in harsh and corrosive environments, making them a dependable solution for a wide range of industrial applications.
Table of content
- Alloy 20 tube fittings Specification
- Types of Alloy 20 compression fittings
- Alloy 20 N08020 instrumentation fittings chemical composition
- Carpenter 20 high pressure compression fittings mechanical composition
- Nickel Alloy 20 ferrule fittings equivalent grade
- Size chart of 20cb3 Alloy 20 male connector
- Incoloy 20 double ferrule fittings Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
Alloy 200 instrumentation fittings
ASTM B160 UNS N02200 ferrule fittings
UNS N02200 hydraulic fittings
Ni200 flare fittings
DIN 2.4066 single ferrule fittings
Ni 200 double ferrule fittings
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
We specialize in producing medium-pressure Incoloy 20 double ferrule fittings that can withstand pressures of up to 22,500 psi
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Experience the advantages of our Alloy 20 pneumatic fittings products as an exporter
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
You can purchase Carpenter 20 bulkhead union at reasonable prices from the supplier.
Application of Alloy 20 pneumatic fittings
- Pharmaceutical equipment
- Petrochemical industry
- Chemical processing
- Beverage industry
- Food processing equipment
Packaging of UNS N08020 bulkhead union
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What are the key features of Alloy 20 compression fittings?
Alloy 20 compression fittings offer excellent resistance to corrosion, particularly in sulfuric acid environments, along with good mechanical properties and fabricability.
What is the temperature range in which Alloy 20 N08020 instrumentation fittings can operate?
Alloy 20 N08020 instrumentation fittings can operate in a temperature range of -29°C (-20°F) to 1040°C (1900°F) without significant loss of corrosion resistance.
How are Carpenter 20 high pressure compression fittings commonly manufactured?
Carpenter 20 high pressure compression fittings are typically manufactured using processes such as seamless or welded tube production, followed by precision machining or forming to achieve the desired fitting shape.
What are the typical applications of Nickel Alloy 20 ferrule fittings?
Nickel Alloy 20 ferrule fittings find applications in industries such as chemical processing, pharmaceuticals, food processing, and synthetic fibers, where resistance to corrosive environments is crucial.
Are 20cb3 Alloy 20 male connector compatible with other materials?
20cb3 Alloy 20 male connector are compatible with a wide range of materials, including stainless steel, carbon steel, and various alloys, making them suitable for various piping and tubing systems.
