Trust us as one of the finest CuNi 90/10 Male tee manufacturers in India
Fit-lok is a well-known Cu 90/10 Compression Tube Fittings manufacturer, stockist, supplier, and exporter. Their use of high-quality raw materials, as well as respect to national and international standards, enables the manufacturing of high-quality Compression Tube Fittings. Cu 90/10, also known as Cupronickel 90/10, is an alloy made composed of 90% copper and 10% nickel, with iron and manganese added to improve its overall qualities. This alloy has a number of properties, including corrosion resistance, stress corrosion cracking, pitting, crevice corrosion, and high strength.
Precise dimensions and sizes for your Cuni 90/10 Bulkhead Union needs.
The company manufactures Cu 90/10 Compression Tube Fittings in a variety of sizes, dimensions, grades, metals, alloys, and requirements, allowing them to provide their clients with properly suited fittings. They provide high-quality Cu 90/10 Compression Tube Fittings with excellent formability and fabricability. These fittings have several desirable characteristics, including longevity, dimensional correctness, high tensile strength, the capacity to handle severe loads, little maintenance, flexibility, and ease of handling.
Fit-lok’s emphasis on quality and client satisfaction has helped them establish themselves as a dependable provider for Cu 90/10 Compression Tube Fittings. The fittings’ exceptional qualities make them suited for a wide range of applications, and their versatility to meet special criteria guarantees that they can meet the varying needs of clients in many industries.
Table of content
- Cupro Nickel 90/10 Tube Fittings Specification
- Types of CuNi 90/10 Compression Fittings
- Copper Nickel 90/10 Double Ferrule Fittings chemical composition
- Cuni 90/10 Bulkhead Union mechanical composition
- 90/10 Copper Nickel Instrumentation Fittings equivalent grade
- Size chart of UNS C70600 90/10 Ferrule Fitting
- DIN 2.0872 Tube Insert Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
CuNi 90/10 Compression Fittings
Copper Nickel 90/10 Double Ferrule Fittings
Cuni 90/10 Bulkhead Union
90/10 Copper Nickel Instrumentation Fittings
UNS C70600 90/10 Ferrule Fitting
DIN 2.0872 Tube Insert
| Grade | Ni | Pb | Cu | Fe | Mn | Zn |
| 90/10 Copper Ni | 9-11 maximum | .05 maximum | 88.6 minimum | 1.8 maximum | 1.0 maximum | 1 maximum |
Obtain 90/10 Copper Nickel Instrumentation Fittings at reasonable prices from the stockholder.
| Density | Elongation | Tensile Strength | Melting Point | Yield Strength (0.2%Offset) |
| 8.1 g/cm3 | 30 % | Psi -80,000, MPa -551 | 1443 °C (2430 °F) | Psi – 35,000, MPa – 2410 |
| STANDARD | WERKSTOFF NR. | UNS |
| Copper Nickel 90/10 | 2.0872 | C70600 |
View the corrosion resistance and thermal expansion properties of our UNS C70600 Ferrule Fitting to ensure durability.
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
Our DIN 2.0872 Tube Insert are meticulously crafted to meet the specific needs of both instrumentation and industrial applications.
Application of Cuni 90/10 Bulkhead Union
- Power generation
- Industrial machinery
- Brewing equipment
- Construction and architecture
- Textile industry
Packaging of Copper Nickel 90/10 Double Ferrule Fittings
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
Can CuNi 90/10 Compression Fittings be exported to international markets?
Yes, CuNi 90/10 Compression Fittings are commonly exported to international markets due to their high demand and wide range of applications in various industries.
What testing procedures are conducted on Copper Nickel 90/10 Double Ferrule Fittings?
Copper Nickel 90/10 Double Ferrule Fittings undergo various tests, including hydrostatic testing, dimensional inspections, material analysis, and corrosion resistance testing, to ensure their quality and performance.
How are Cuni 90/10 Bulkhead Union typically packed for shipment?
Cuni 90/10 Bulkhead Union are usually packed in sturdy wooden cases or crates to ensure safe transportation and protection against damage during transit.
Do 90/10 Copper Nickel Instrumentation Fittings come with relevant quality certificates?
Yes, 90/10 Copper Nickel Instrumentation Fittings are often supplied with quality certificates such as Material Test Reports (MTRs) and Certificates of Conformance, ensuring compliance with industry standards and specifications.
Are UNS C70600 90/10 Ferrule Fitting eligible for third-party inspection?
Yes, UNS C70600 90/10 Ferrule Fitting can undergo third-party inspection by accredited inspection agencies to validate their quality, performance, and adherence to applicable standards.
