We are top notch Duplex 2205 hydraulic ball valve Manufacturer in India
Call us to get latest stock and price list of Duplex steel ball valve
Table of content
| Working Pressure | Up to 6000 PSIG |
| End Connection | Male to Female, Male and Female NPT, Socket Weld (SW) or Dual Ferrule Tube Connections, BSPT, Female to Female |
| Sizes | 1/8 to 4”, Sizes available on request |
| Pressure rating | 150#, 300#, 600#, 900#, 1500# |
| Cr | Ni | Mo | C | N |
| 22.0-23.0 | 4.50-6.50 | 3.00-3.50 | .030 Max | 0.14-0.20 |
| Mn | Si | P | S | Fe |
| 2.00 Max | 1.00 Max | .030 Max | .020 Max | Balance |
| Duplex Stainless Steel | |
| Density | 7.805 |
| Melting Range,℃ | 1450 ℃ |
| Elongation % | 25 min. |
| Tensile Strength (Mpa) | 655 |
| Yield Strngth (Mpa) | 450 |
| Hardness (Brinell) | 293 max |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex 2205 | 1.4462 | S31803, S32205 |
| NPS | PSIG |
|---|---|
| 1/2 – 1-1/2 | 1000 PSIG (69 BARG) |
| 2 | 800 PSIG (55 BARG) |
| 3 | 600 PSIG (41 BARG) |
| 4-5 | 500 PSIG (34 BARG) |
| 6 | 300 PSIG (21 BARG) |
| END CONNECTION SIZE | ORIFICE | A | |||
|---|---|---|---|---|---|
| (IN) | (MM) | (IN) | (MM) | (IN) | (MM) |
| 1/8 | 3.17 | 0.09 | 2.4 | 1.01 | 25.5 |
| 3/16 | 4.76 | 0.13 | 3.2 | 1.1 | 28 |
| 1/4 | 6.35 | 0.19 | 4.8 | 1.2 | 30 |
| 3/8 | 9.52 | 0.28 | 7.1 | 1.45 | 36.5 |
| 1/2 | 12.7 | 0.41 | 10.3 | 1.74 | 44.2 |
| 0.12 | 3 | 0.09 | 2.4 | 1.01 | 25.5 |
| 0.24 | 6 | 0.19 | 4.8 | 1.2 | 30 |
| 0.31 | 8 | 0.19 | 4.8 | 1.23 | 31.2 |
| 0.39 | 10 | 0.28 | 7.1 | 1.45 | 36.5 |
| 0.47 | 12 | 0.41 | 10.3 | 1.74 | 44.2 |
