We are dedicated to being the premier UNS N10276 compression fittings manufacturer in India
Fit-lok is a leading supplier of Hastelloy C276 Instrumentation Tube Fittings, with an emphasis on providing outstanding solutions for important industrial applications. Our dedication to excellence and client satisfaction has earned us the industry’s preferred choice. We make high-quality Alloy C276 male elbow in a short period of time using cutting-edge technology, contemporary machinery, and well-defined manufacturing techniques, ensuring both efficiency and quality.
Fit-lok is dedicated to producing high-quality goods, like Nickel Alloy C276 hydraulic fittings. To ensure precise production, we use cutting-edge technology and contemporary machinery, as well as well-defined manufacturing methods. Our rigorous inspection and quality control procedures ensure that each unique fitting fulfils the highest quality standards and performs admirably.
Obtain C276 Hastelloy ferrule fittings at affordable prices from the stockist.
UNS N10276 high pressure compression fittings are used in industrial industries such as Chemical processing, petrochemical, oil and gas and power generation. They are suited for demanding applications due to their improved corrosion resistance, high-temperature stability, and precision manufacture. Hastelloy Alloy C276 flare fittings enable leak-free couplings and dependable fluid and gas transfer, hence improving the overall efficiency and safety of industrial processes. We produce UNS N10276 male connectors that require low maintenance and provide long-lasting performance by using the best quality materials and adhering to strict production methods, providing our client’s piece of mind.
Table of content
- Hastelloy C276 tube fittings Specification
- Types of Hastelloy C276 compression fittings
- Alloy C276 instrumentation fittings chemical composition
- UNS N10276 high pressure compression fittings mechanical composition
- C276 Hastelloy ferrule fittings equivalent grade
- Size chart of SB 564 UNS N10276 male connector
- DIN 2.4819 double ferrule fittings Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
UNS N10276 high pressure compression fittings
C276 Hastelloy ferrule fittings
SB 564 UNS N10276 male connector
Nickel Alloy C276 hydraulic fittings
Hastelloy Alloy C276 flare fittings
Nickel Alloy UNS N10276 single ferrule fittings
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
View the thermal conductivity and chemical resistance properties of our UNS N10276 male connector for diverse applications.
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Trust us to deliver ASTM B564 N10276 compression tube fittings that excel in both instrumentation and industrial applications.
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
Exporter of Alloy C276 instrumentation fittings with labor-saving installation and cost reduction
Application of UNS N10276 high pressure compression fittings
- Dairy equipment
- Brewing equipment
- Aerospace industry
- Marine applications
- Automotive manufacturing
Packaging of Alloy C276 instrumentation fittings
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
Are Alloy C276 instrumentation fittings suitable for sour gas applications?
Yes, Alloy C276 instrumentation fittings have excellent resistance to sour gas environments containing hydrogen sulfide (H2S), making them suitable for oil and gas applications.
Can UNS N10276 high pressure compression fittings be used in high-pressure systems?
Yes, UNS N10276 high pressure compression fittings are designed to withstand high-pressure conditions, making them suitable for applications where pressure containment is critical.
Do C276 Hastelloy ferrule fittings exhibit resistance to intergranular corrosion?
Yes, C276 Hastelloy ferrule fittings have low carbon content, ensuring resistance to intergranular corrosion even in welded conditions.
What is the size range for SB 564 UNS N10276 male connector?
SB 564 UNS N10276 male connector are available in a wide range of sizes, from small diameter tubes to larger sizes, accommodating various piping requirements.
Can Nickel Alloy C276 hydraulic fittings be used in highly acidic environments?
Yes, Nickel Alloy C276 hydraulic fittings demonstrate excellent resistance to a wide range of acidic environments, including sulfuric acid, hydrochloric acid, and nitric acid.
