Top notch ASTM B622 UNS N10276 Seamless tube supplier in India
The chemical composition of Hastelloy C276 Tube includes nickel, chromium, and molybdenum. This is a solid solution reinforced superalloy with tungsten, cobalt, and iron as chemical constituents. Hastelloy C276 Tube is the tradename, while UNS N10276 is the designation. Hastelloy 2.4819 Welded Tube is regarded as one of the most adaptable alloys for effective corrosion resistance. It can be used in severely corrosive settings that most other alloys cannot.
Hastelloy C276 High Pressure Tube have excellent weldability properties
The Alloy C276 Heat Exchanger Tube is also resistant to oxidation at temperatures as high as 1038 degrees Celsius. The Hastelloy C276 Seamless Tube has a yield strength of 345 MPa when annealed, and it can be strengthened further by the pigler process. Even at cryogenic temperatures, the material has outstanding hardness.
The ASME SB 622 N10276 Round Tube creep test provides information regarding material deformation as a function of time. When it is subjected to constant loading at a specific temperature. The stress test, on the other hand, provides information on the ASTM B622 UNS N10276 material’s load-carrying capacity. It is calculated when the material is subjected to steady stress for an extended period of time at a high temperature. As a result, these tests serve to lower the possibility of failure of the ASME SB 622 N10276 Round Tube as it operates.
Table of content
| Specification | ASTM B163 / ASME SB163 |
| Surfaces | |
| Standard length | 6 metres |
| Delivery Condition | MF, Bright Annealed, Polished, Annealed and Pickled, Cold Drawn |
| Thickness Range | Schedule 5 to Schedule XXS |
| Manufacturing Type | CEW / Seamless / DOM / ERW / Fabricated / Welded / CDW / CDS / 100% X Ray Welded |
| Surface Finish | BA, 500G, 2B, No.1, No.3, No.8, 800G Mirror finish, 8K, HL, No.4, 2D, Mirror Polished, 1D, 180G, 400G Satin/ Hairline, 320G, 400G, 600G |
| Value Added Services |
|
| END | Plain End, Beveled End, Treaded Tubes |
| Processing Service | Welding, Decoiling, Bending, Punching, Cutting, Moulding |
| Technique | Cold drawn, Cold rolled, Hot rolled, Extrusion Tubes |
| Tolerance |
Hastelloy C276 High Pressure Tube
C276 Alloy Round Tube
Alloy C276 Electropolished Tubes
DIN NR. 2.4819 ERW Tube
Nickel Alloy C276 Capillary Tubing
ASTM B622 Hastelloy C276 Square Tubing
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Contact us now to discuss and obtain a fair and reasonable price for high C276 Alloy Round Tube and Nickel C276 Electropolished Tubes.
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
The weight of DIN 2.4819 ERW Tube and Ni C276 Capillary Tubing varies depending on the size and wall thickness, with standard weights ranging from 0.28 lbs/ft to 93.17 lbs/ft.
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
| Wall Thickness | Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Wide selection of UNS N10276 Square Tubing dimensions and sizes to meet your specific needs
| OD inches | Ave. Wall inches | D/t Ratio | ID inches | Tube Cross Sectional Area (in2) | Internal Area (in2) |
|---|---|---|---|---|---|
| 0.250 | 0.020 | 12.50 | 0.210 | 0.0145 | 0.0346 |
| 0.250 | 0.028 | 8.93 | 0.194 | 0.0195 | 0.0296 |
| 0.250 | 0.035 | 7.14 | 0.180 | 0.0236 | 0.0254 |
| 0.250 | 0.049 | 5.10 | 0.152 | 0.0309 | 0.0181 |
| 0.250 | 0.065 | 3.85 | 0.120 | 0.0378 | 0.0113 |
| 0.375 | 0.020 | 18.75 | 0.335 | 0.0223 | 0.0881 |
| 0.375 | 0.028 | 13.39 | 0.319 | 0.0305 | 0.0799 |
| 0.375 | 0.035 | 10.71 | 0.305 | 0.0374 | 0.0731 |
| 0.375 | 0.049 | 7.65 | 0.277 | 0.0502 | 0.0603 |
| 0.375 | 0.065 | 5.77 | 0.245 | 0.0633 | 0.0471 |
| 0.500 | 0.020 | 25.00 | 0.460 | 0.0302 | 0.1662 |
| 0.500 | 0.028 | 17.86 | 0.444 | 0.0415 | 0.1548 |
| 0.500 | 0.035 | 14.29 | 0.430 | 0.0511 | 0.1452 |
| 0.500 | 0.049 | 10.20 | 0.402 | 0.0694 | 0.1213 |
| 0.500 | 0.065 | 7.69 | 0.370 | 0.0888 | 0.1075 |
| 0.500 | 0.083 | 6.02 | 0.334 | 0.1087 | 0.0876 |
| 0.625 | 0.020 | 31.25 | 0.585 | 0.0380 | 0.2688 |
| 0.625 | 0.028 | 22.32 | 0.569 | 0.0525 | 0.2543 |
| 0.625 | 0.035 | 17.86 | 0.555 | 0.0649 | 0.2419 |
| 0.625 | 0.049 | 12.76 | 0.527 | 0.0887 | 0.2181 |
| 0.625 | 0.065 | 9.62 | 0.495 | 0.1144 | 0.1924 |
| 0.625 | 0.083 | 7.53 | 0.459 | 0.1413 | 0.1655 |
| 0.625 | 0.095 | 6.58 | 0.435 | 0.1582 | 0.1486 |
| 0.625 | 0.109 | 5.73 | 0.407 | 0.1767 | 0.1301 |
| 0.750 | 0.028 | 26.79 | 0.694 | 0.0635 | 0.3783 |
| 0.750 | 0.035 | 21.43 | 0.680 | 0.0786 | 0.3632 |
| 0.750 | 0.049 | 15.31 | 0.652 | 0.1079 | 0.3339 |
| 0.750 | 0.065 | 11.54 | 0.620 | 0.1399 | 0.3019 |
| 0.750 | 0.083 | 9.04 | 0.584 | 0.1739 | 0.2679 |
| 0.750 | 0.095 | 7.89 | 0.560 | 0.1955 | 0.2463 |
| 0.750 | 0.109 | 6.88 | 0.532 | 0.2195 | 0.2223 |
| 0.750 | 0.120 | 6.25 | 0.510 | 0.2375 | 0.2043 |
| 0.875 | 0.020 | 43.75 | 0.835 | 0.0537 | 0.5476 |
| 0.875 | 0.028 | 31.25 | 0.819 | 0.0745 | 0.5268 |
| 0.875 | 0.035 | 25.00 | 0.805 | 0.0924 | 0.5090 |
| 0.875 | 0.049 | 17.86 | 0.777 | 0.1272 | 0.4742 |
| 0.875 | 0.065 | 13.46 | 0.745 | 0.1654 | 0.4359 |
| 0.875 | 0.083 | 10.54 | 0.709 | 0.2065 | 0.3948 |
| 0.875 | 0.095 | 9.21 | 0.685 | 0.2328 | 0.3685 |
| 0.875 | 0.109 | 8.03 | 0.657 | 0.2623 | 0.3390 |
| 0.875 | 0.120 | 7.29 | 0.635 | 0.2846 | 0.316L7 |
| 1.000 | 0.028 | 35.71 | 0.944 | 0.0855 | 0.6999 |
| 1.000 | 0.035 | 28.57 | 0.930 | 0.1061 | 0.6793 |
| 1.000 | 0.049 | 20.41 | 0.902 | 0.1464 | 0.6390 |
| 1.000 | 0.065 | 15.38 | 0.870 | 0.1909 | 0.5945 |
| 1.000 | 0.083 | 12.05 | 0.834 | 0.2391 | 0.5463 |
| 1.000 | 0.095 | 10.53 | 0.810 | 0.2701 | 0.5153 |
| 1.000 | 0.109 | 9.17 | 0.782 | 0.3051 | 0.4803 |
| 1.000 | 0.120 | 8.33 | 0.760 | 0.3318 | 0.4536 |
| 1.000 | 0.134 | 7.46 | 0.732 | 0.3646 | 0.4208 |
| 1.250 | 0.035 | 35.71 | 1.180 | 0.1336 | 1.0936 |
| 1.250 | 0.049 | 25.51 | 1.152 | 0.1849 | 1.0423 |
| 1.250 | 0.065 | 19.23 | 1.120 | 0.2420 | 0.9852 |
| 1.250 | 0.083 | 15.06 | 1.084 | 0.316L3 | 0.9229 |
| 1.250 | 0.095 | 13.16 | 1.060 | 0.3447 | 0.8825 |
| 1.250 | 0.109 | 11.47 | 1.032 | 0.3907 | 0.8365 |
| 1.250 | 0.120 | 10.42 | 1.010 | 0.4260 | 0.8012 |
| 1.250 | 0.134 | 9.33 | 0.982 | 0.4698 | 0.7574 |
| 1.500 | 0.035 | 42.86 | 1.430 | 0.1611 | 1.6061 |
| 1.500 | 0.049 | 30.61 | 1.402 | 0.2234 | 1.5438 |
| 1.500 | 0.065 | 23.08 | 1.370 | 0.2930 | 1.4741 |
| 1.500 | 0.083 | 18.07 | 1.334 | 0.3695 | 1.3977 |
| 1.500 | 0.095 | 15.79 | 1.310 | 0.4193 | 1.3478 |
| 1.500 | 0.109 | 13.76 | 1.282 | 0.4763 | 1.2908 |
| 1.500 | 0.120 | 12.50 | 1.260 | 0.5202 | 1.2469 |
| 1.500 | 0.134 | 11.19 | 1.232 | 0.5750 | 1.1921 |
| 1.500 | 0.148 | 10.14 | 1.204 | 0.6286 | 1.1385 |
| 1.750 | 0.035 | 50.00 | 1.680 | 0.1886 | 2.2167 |
| 1.750 | 0.049 | 40.82 | 1.902 | 0.3003 | 2.8413 |
| 1.750 | 0.065 | 26.92 | 1.620 | 0.3441 | 2.0612 |
| 1.750 | 0.083 | 21.08 | 1.584 | 0.4347 | 1.9706 |
| 1.750 | 0.095 | 18.42 | 1.560 | 0.4939 | 1.9113 |
| 1.750 | 0.109 | 16.06 | 1.532 | 0.5619 | 1.8433 |
| 1.750 | 0.120 | 14.58 | 1.510 | 0.6145 | 1.7908 |
| 1.750 | 0.134 | 13.06 | 1.482 | 0.6803 | 1.7250 |
| 1.750 | 0.148 | 11.82 | 1.454 | 0.7449 | 1.6604 |
| 1.750 | 0.165 | 10.61 | 1.420 | 0.8216 | 1.5837 |
| 2.000 | 0.035 | 57.14 | 1.930 | 0.2161 | 2.9255 |
| 2.000 | 0.049 | 40.82 | 1.902 | 0.3003 | 2.8413 |
| 2.000 | 0.065 | 30.77 | 1.870 | 0.3951 | 2.7465 |
| 2.000 | 0.083 | 24.10 | 1.834 | 0.4999 | 2.6417 |
| 2.000 | 0.095 | 21.05 | 1.810 | 0.5685 | 2.5730 |
| 2.000 | 0.109 | 18.35 | 1.782 | 0.6475 | 2.4941 |
| 2.000 | 0.120 | 16.67 | 1.760 | 0.7087 | 2.4328 |
| 2.000 | 0.134 | 14.93 | 1.732 | 0.7855 | 2.3561 |
| 2.000 | 0.148 | 13.51 | 1.704 | 0.8611 | 2.2805 |
| 2.000 | 0.165 | 12.12 | 1.670 | 0.9512 | 2.1904 |
Application of hastelloy c276 seamless tube
- Dairy equipment
- Automotive manufacturing
- Aerospace industry
- Marine applications
- Brewing equipment
Packaging of UNS N10276 Tubing
Safeguard delicate items with plastic or paper sleeves when bundling them for shipment. Wooden crates are sturdy and reliable packaging solutions for transporting goods securely. Cardboard boxes are versatile and eco-friendly options for organizing your items during transit.
Frequently asked questions
What industries commonly utilize hastelloy c276 seamless tube?
hastelloy c276 seamless tube are commonly utilized in industries such as marine, oil and gas, chemical processing, aerospace, and power generation.
Are C276 Hastelloy Welded Tube resistant to pitting and crevice corrosion?
Yes, C276 Hastelloy Welded Tube exhibit good resistance to pitting and crevice corrosion, which makes them suitable for applications in corrosive environments.
Can Hastelloy UNS N10276 Tubing be used in seawater applications without significant degradation?
Hastelloy UNS N10276 Tubing have excellent resistance to corrosion in seawater, making them suitable for marine applications without significant degradation.
Are Hastelloy C276 High Pressure Tube easily formable and weldable?
Hastelloy C276 High Pressure Tube can be easily formed and welded using conventional techniques such as TIG (Tungsten Inert Gas) and MIG (Metal Inert Gas) welding.
What is the maximum pressure rating for C276 Alloy Round Tube?
The maximum pressure rating for C276 Alloy Round Tube depends on various factors such as tube dimensions, wall thickness, and temperature, and should be determined based on specific design requirements.
