Hastelloy manifold valve

Check available sizes of Hastelloy c22 manifold valve

Table of content

Hastelloy manifold valve specification

Size 50NB — 600NB
Pressure 150PS1
Temperature 0 Deg C – 1200 Deg C.
Body , Chest Solid One piece casting of Cast Iron Fg 260, Cast Steel Gr WCB ,CF8,CF8M.
Seat Integral to Body, Soft, Optional.
Gate AISI SS 304,316,316L,317,317L
Screw Spindle AISI SS 410,304,316.
Nut Brass
Yoke Plate type of MS .
Gland Follower Cast Iron , Cast steel , Ductile Iron ,CF8,CF8M.
Hand Wheel Cast Iron , Cast steel , Ductile Iron
Gland Packing PTFE , PTFE Impregnated
Ends Lugged
Port STANDARD [Round], Optional V Port, Diamond Port,.

Hastelloy manifold control valve chemical composition

Grade C Mn Si S Co Ni Cr Fe Mo P
C276 0.010 max 1.00 max 0.08 max 0.03 max 2.50 max 50.99 min* 14.50 – 16.50 4.00 – 7.00 15.00 – 17.00 0.04 max
C22 0.010 max 0.50 max 0.08 max 0.02 max 2.50 max 50.015 min* 20.00 – 22.50 2.00 – 6.00 12.50 – 14.50 0.02 max
B2 0.02 max 1.0 max 0.1 max 0.03 max 1.0 max Bal 1.0 max 2.0 max 26 – 30 0.04 max

Hastelloy alloy manifold tuning valve Mechanical properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Hastelloy C276 8.89 g/cm3 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 Psi – 52,000 , MPa – 355 40 %
Hastelloy C22 8.69 g/cm3 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 Psi – 45000 , MPa – 310 45 %
Hastelloy B2 9.2 g/cm3 1370 °C (2500 ºF ) Psi – 1,10,000 , MPa – 760 Psi – 51000 , MPa – 350 40 %

Equivalent grade of Hastelloy manifold valves

STANDARD WERKSTOFF NR. UNS JIS GOST EN OR
Hastelloy C276 2.4819 N10276 NW 0276 ХН65МВУ NiMo16Cr15W ЭП760
Hastelloy C22 2.4602 N06022 NW 6022 – NiCr21Mo14W –
Hastelloy B2 2.4617 N10665 – – – –

Pressure Rating Of Hastelloy C276 manifold valve

Operating pressure Max.: 700 bar (10,153 psi)

Size Chart of Alloy C22 manifold check valve

Connections C End Connection LG THK Top/Bottom Connection Width
4 1.38 HF9 5.26 1.5 HF6 2.63
6 1.38 HF9 7.76 1.5 HF6 2.63
8 1.38 HF9 10.26 1.5 HF6 2.63
10 1.38 HF9 12.76 1.5 HF6 2.63
14 1.38 HF9 17.76 1.5 HF6 2.63
