Make us your preferred Alloy 625 Reducer Union manufacturer in India.
We are a well-known manufacturer and supplier of Inconel 625 Instrumentation Fittings. Our dedication to delivering excellence and satisfying customer expectations has made us a popular choice in the business.
Alloy 625 Reducer Union is essential in many industries, including oil & gas, chemical, petrochemical, and power generating. These Alloy 625 high pressure compression fittings are used to make secure connections between instrumentation components, allowing for precise fluid and gas measurement and control. The fittings’ integrity and reliability are critical for accurate readings and the smooth functioning of instrumentation equipment.
ASTM B564 UNS N06625 ferrule fittings are a nickel-chromium-based alloy that is extremely resistant to corrosion and high temperatures. It is made up of nickel, chromium, molybdenum, and niobium, among other elements. Alloy Inconel 625 single ferrule fittings are well-known for their exceptional strength, durability, and resistance to corrosive environments such as seawater, acids, and oxidizing agents.
Purchase ASTM B564 UNS N06625 ferrule fittings and Alloy 625 single ferrule fittings directly from the supplier at reasonable prices.
UNS N06625 double ferrule fittings are made to be simple to install. Their precise dimensions and standardized threading allow for easy integration into instrumentation systems, shortening installation time and assuring a safe, leak-free connection.
Inconel 625 hydraulic fittings content gives great strength and stability at high temperatures. 2.4856 Inconel male connectors can maintain structural integrity even in high temperatures, allowing them to be used in applications requiring thermal cycle resistance and high-temperature exposure.
Table of content
- Inconel 625 tube fittings Specification
- Types of Inconel 625 compression fittings
- UNS N06625 instrumentation fittings chemical composition
- Alloy 625 high pressure compression fittings mechanical composition
- DIN 2.4856 bulkhead union equivalent grade
- Size chart of Nickel 625 compression tube fittings
- Alloy 625 flare fittings Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
ASTM B564 UNS N06625 ferrule fittings
Alloy Inconel 625 single ferrule fittings
UNS N06625 double ferrule fittings
Inconel 6625 hydraulic fittings
Nickel Alloy 625 pneumatic fittings
2.4856 Inconel male connector
| Grade | C | Mn | Si | Fe | S | Cr2 | Al-Ti | Ni | |
|---|---|---|---|---|---|---|---|---|---|
| 625 | min. | – | – | – | – | – | 20.0 | – | 58.0 |
| max. | 0.10 | 0.50 | 0.50 | 5.0 | 0.015 | 23.0 | 0.40 | – | |
View the fatigue strength and transparency properties of our UNS N06625 double ferrule fittings and Inconel 625 hydraulic fittings for versatile applications.
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
|---|---|---|---|---|---|
| 625 | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 | – | – |
| STANDARD | WNR Material Number | JIS | EN | BS | UNS | AFNOR | GOST |
| 625 | 2.4856 | NCF 625 | NiCr22Mo9Nb | NA 21 | N06625 | NC22DNB4M | ХН75МБТЮ |
Our DIN 2.4856 male connector and Alloy 625 bulkhead union are specifically designed to meet the demands of both instrumentation and industrial usage.
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
Exporter of Nickel 625 compression tube fittings and UNS N06625 flare fittings with streamlined installation and reduced labor expenses
Application of Inconel 625 tube fittings
- Water treatment
- HVAC systems
- Automotive applications
- Aerospace industry
- Marine applications
Packaging of ASTM B564 UNS N06625 ferrule fittings
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What is the temperature range for Inconel 625 tube fittings?
Inconel 625 tube fittings can typically operate in temperatures ranging from cryogenic (-423°F/-253°C) up to 1800°F (982°C), offering excellent high-temperature performance.
Are ASTM B564 UNS N06625 ferrule fittings resistant to corrosion?
Yes, ASTM B564 UNS N06625 ferrule fittings exhibit exceptional resistance to various corrosive environments, including acids, seawater, and oxidizing media.
Can Inconel 625 bulkhead union be used in sour gas service?
Yes, Inconel 625 bulkhead union have excellent resistance to hydrogen sulfide (H2S) and are commonly used in sour gas environments.
What is the pressure rating for Nickel 625 tube fittings?
The pressure rating for Nickel 625 tube fittings varies depending on factors such as size and design, but they can typically handle high-pressure applications up to several thousand psi.
What industries commonly utilize UNS N06625 double ferrule fittings?
UNS N06625 double ferrule fittings find applications in industries such as oil and gas, chemical processing, and aerospace, where resistance to corrosion, high temperatures, and pressure is required.
