We are leading Inconel 600 Tube Fittings manufacturer in India
Inconel Instrumentation tube Fittings is a nickel-chromium alloy noted for its outstanding strength and heat resistance. It has good corrosion resistance in a variety of settings, making it a preferred choice for applications requiring endurance and dependability. Inconel 600 Tube Fittings offer dependable solutions for fluid management systems operating in high-temperature environments. Nickel 600 Compression Fittings is well-known for its strength and ability to retain mechanical qualities at high temperatures, making it a dependable choice for extreme-condition applications.
Buy Inconel 600 Double Ferrule Tube Fittings at reasonable rates from the stockholder.
Alloy 600 Imperial Fittings are essential components in fluid control systems because they ensure leak-free connections and optimal flow control. 6000PSI Inconel Compression Tube provide dependable solutions for applications involving high temperatures and corrosive conditions. These UNS N06600 Double Ferrule Tube Fittings are built to endure harsh environments, making them ideal for use in industries such as chemical processing, aerospace, and power generation.
Table of content
- Inconel Tube Fittings Specification
- Types of Inconel 600 Tube Fittings
- Inconel 600 Compression Fittings chemical composition
- Inconel 600 UNS N06600 Air Fittings mechanical composition
- Inconel UNS No 6600 Compression Fittings equivalent grade
- Size chart of Alloy Inconel 600 Bulkhead Tube Fittings
- Inconel Alloy 600 Imperial Fittings Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
Inconel 600 Compression Fittings
Alloy 600 Imperial Fittings
6000PSI Inconel Compression Tube
Nickel 600 Ferrule Tube Fittings
UNS N06600 Single Ferrule Fittings
Din 2.4816 Double Ferrule Tube Fittings
| Grade | C | Mn | Si | Fe | S | Cr | Cu | Ni | |
|---|---|---|---|---|---|---|---|---|---|
| 600 | min. | – | – | – | 6.0 | – | 14.0 | – | 72.0 |
| max. | 0.15 | 1.0 | 0.5 | 10.0 | 0.015 | 17.0 | 0.5 | – | |
Whether you require UNS N06600 Bulkhead Tube Fittings for instrumentation or industrial purposes, we have you covered.
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 600 | Psi – 95,000 , MPa -655 | Psi – 45,000 , MPa – 310 | 40 | – | – |
| Grade | UNS No | Old British | Euronorm | GOST | Japanese JIS | ||
|---|---|---|---|---|---|---|---|
| BS | En | No | AFNOR | ||||
| Inconel 600 | N06600 | NA 13 | NiCr15Fe | 2.4816 | NC15FE11M | МНЖМц 28-2,5-1,5 | NCF 600 |
Discover the electrical resistivity and impact strength properties of our Nickel 600 Imperial Fittings for efficient usage.
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
Efficient exporter of 6000PSI Alloy Compression Tube fittings with simplified installation and cost savings
Application of Inconel 600 Tube Fittings
- Food processing equipment
- Beverage industry
- Chemical processing
- Petrochemical industry
- Pharmaceutical equipment
Packaging of Alloy 600 Double Ferrule Tube Fittings
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What are the advantages of using Inconel instrumentation tube fittings in high-temperature applications?
Inconel instrumentation tube fittings offer excellent high-temperature strength, oxidation resistance, and thermal stability.
Can Inconel 600 Tube Fittings be used in corrosive environments?
Yes, Inconel 600 Tube Fittings exhibit exceptional resistance to corrosion, including in acidic and chloride-rich environments.
Are Alloy 600 Double Ferrule Tube Fittings compatible with stainless steel tubing?
Yes, Alloy 600 Double Ferrule Tube Fittings are compatible with stainless steel tubing, allowing for versatile system configurations.
What is the maximum pressure rating for Nickel 600 tube fittings?
The maximum pressure rating for Nickel 600 tube fittings depends on factors such as size and design, but they can typically handle high-pressure applications.
What are the common applications of 6000PSI Inconel Compression Tube?
6000PSI Inconel Compression Tube are commonly used in industries such as aerospace, petrochemical, and power generation, where resistance to high temperatures and corrosion is essential.
