We are leading supplier and exporter of DIN 3015-1 light duty pipe
Light-duty tube clamps are simple but effective clamps used to secure tubes in place. They are made from lightweight materials like aluminum and come in different sizes and designs to fit various tube diameters. These clamps are designed to secure tubes to a surface while allowing for easy installation and removal.
We are stockist of Light Series Tube Clamps in wide range of sizes
When it comes to securing tubes in various applications, light-duty tube clamps are a popular choice. These clamps provide a secure grip while allowing for easy installation and removal of tubes. Whether you’re working with hydraulic or pneumatic systems, these clamps can provide the necessary support and protection for your tubes.
Table of content
| Material | Carbon steel , Stainless Steel 304 , Stainless steel 316 , As per client Request. |
| Material | Jaws – Polypropylene, Polyamide, Aluminum |
| Color | Green |
| Structure | Hydraulic |
| Usage/Application | Pipe Fitting |
| Clamp Type | HYDRAULIC |
| Surface Type | Galvanized |
| Condition | New |
| Din | 3015 |
| Type | Standard (Light Duty) |
| Size | 1 /4’’ to 2 ½’’ – 6 mm to 76.1 mm |
| Pressure | 1500 PSI for Light Duty and more than 1500 PSI for Heavy Duty |
Light duty tube clamps
DIN 3015-1 light duty pipe
Light Series Tube Clamps
- Durability
- Compact design
- Easy to install
| PIPE SIZE | MAX. RECOM. LOAD, lbs. | B | C | D | E | F | G | H | APPROX. WEIGHT | |
|---|---|---|---|---|---|---|---|---|---|---|
| @ 650° F | @ 750° F | lbs. per each | ||||||||
| 1/2 | 950 | 850 | 15/16 | 5/16 | 2 7/8 | 2 7/16 | 3/8 | 3/16 x 1 | 1 3/8 | 0.66 |
| 3/4 | 950 | 850 | 15/16 | 5/8 | 2 7/8 | 2 7/16 | 3/8 | 3/16 x 1 | 1 3/8 | 0.70 |
| 1 | 950 | 850 | 1 1/16 | 5/8 | 3 | 2 9/16 | 3/8 | 3/16 x 1 | 1 1/2 | 0.76 |
| 1 1/4 | 950 | 850 | 1 1/4 | 5/8 | 3 1/8 | 2 11/16 | 3/8 | 3/16 x 1 | 1 11/16 | 0.81 |
| 1 1/2 | 1545 | 1380 | 1 13/16 | 1 1/16 | 4 7/8 | 4 1/8 | 5/8 | 1/4 x 1 1/4 | 2 3/8 | 2.30 |
| 2 | 1545 | 1380 | 2 1/8 | 1 1/16 | 5 7/8 | 5 1/8 | 5/8 | 1/4 x 1 1/4 | 2 11/16 | 2.60 |
| 2 1/2 | 1545 | 1380 | 2 5/16 | 1 1/16 | 6 1/8 | 5 3/8 | 5/8 | 1/4 x 1 1/4 | 2 15/16 | 2.70 |
| 3 | 1545 | 1380 | 2 3/4 | 1 1/16 | 6 11/16 | 5 15/16 | 5/8 | 1/4 x 1 1/4 | 3 1/2 | 3.00 |
| 4 | 2500 | 2230 | 3 3/8 | 1 1/16 | 7 5/8 | 6 1/2 | 3/4 | 5/16 x 2 | 4 1/2 | 6.70 |
| 5 | 2500 | 2230 | 3 15/16 | 1 1/16 | 8 1/8 | 7 | 3/4 | 5/16 x 2 | 5 | 7.00 |
| 6 | 2865 | 2555 | 4 3/4 | 1 7/16 | 9 11/16 | 8 9/16 | 7/8 | 3/8 x 2 1/2 | 6 1/8 | 11.50 |
| 8 | 2865 | 2555 | 5 3/4 | 1 7/16 | 10 11/16 | 9 9/16 | 7/8 | 3/8 x 2 1/2 | 7 1/8 | 13.20 |
| 10 | 3240 | 2890 | 6 7/8 | 1 7/16 | 12 | 10 5/8 | 1 | 1/2 x 2 1/2 | 8 1/4 | 19.80 |
| 12 | 3240 | 2890 | 7 7/8 | 1 7/16 | 13 | 11 5/8 | 1 | 1/2 x 2 1/2 | 9 1/4 | 22.30 |
| 14 | 4300 | 3835 | 9 1/16 | 2 | 14 5/16 | 12 11/16 | 1 1/4 | 5/8 x 3 | 10 11/16 | 37.70 |
| 16 | 4300 | 3835 | 10 1/16 | 2 | 15 5/16 | 13 11/16 | 1 1/4 | 5/8 x 3 | 11 11/16 | 41.40 |
| 18 | 4300 | 3835 | 11 1/16 | 2 | 16 5/16 | 14 11/16 | 1 1/4 | 5/8 x 3 | 12 11/16 | 44.90 |
| 20 | 4500 | 4015 | 12 3/8 | 2 | 17 5/8 | 15 7/8 | 1 1/2 | 3/4 x 3 | 14 | 57.30 |
| 24 | 4500 | 4015 | 14 3/8 | 2 | 19 5/8 | 17 7/8 | 1 1/2 | 3/4 x 3 | 16 | 65.90 |
| 28 | 6000 | 5340 | 17 1/2 | 2 1/4 | 24 1/4 | 21 3/4 | 1 1/2 | 3/4 x 4 | 20 | 112.30 |
| 30 | 7500 | 6675 | 18 1/2 | 2 1/2 | 26 1/8 | 23 3/8 | 1 1/2 | 3/4 x 5 | 21 1/4 | 150.00 |
| 36 | 10500 | 9345 | 22 1/2 | 3 | 32 1/4 | 28 3/4 | 1 3/4 | 1 x 5 | 26 | 257.50 |
