One of the best UNS S31635 male elbow manufacturer in India
Because to the presence of titanium in their composition, Stainless steel 316Ti tube fittings are noted for their remarkable corrosion resistance. These fittings’ titanium atoms mix with carbon atoms to produce titanium carbides, which are exceptionally stable and resistant to dissolution in the alloy.
stainless steel 316Ti compression fittings are well known for their exceptional corrosion resistance and durability. These fittings are intended for hydraulic systems that require reliable and leak-free connections. Because of their improved resistance to intergranular corrosion, they find use in a variety of industries, including oil and gas, chemical processing, and maritime settings.
Reliable supplier providing competitive rates for high-quality ASTM A276 316Ti pipe connectors and SUS 316Ti tube connectors in India
stainless steel 316Ti adapter fittings are manufactured under various conditions to satisfy the needs of certain applications. Depending on the necessary features, the fittings can be hot-finished or cold-finished. DIN 1.4571 high pressure fittings are annealed, offering good ductility and formability. Components that have been hardened and tempered are referred to as condition H, as they have increased strength and hardness. Similarly, fittings supplied in condition S are strain hardened or mildly cold worked, providing increased deformation resistance.
To determine the qualities of ASTM A276 316Ti pipe connectors, mechanical tests are performed. Elongation, Brinell hardness, tensile strength, and yield strength are among the tests performed. AISI 316Ti npt tube fittings have outstanding mechanical features such as high tensile strength, good elongation, and resistance to deformation.
Table of content
- Stainless steel 316Ti tube fittings Specification
- Types of stainless steel 316Ti compression fittings
- 316Ti stainless steel tube fittings chemical composition
- stainless steel 316Ti adapter fittings mechanical composition
- 316Ti stainless steel instrumentation fittings equivalent grade
- Size chart of DIN 1.4571 high pressure fittings
- ASTM A182 F 316Ti instrumentation tube fittings Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
316Ti stainless steel tube fittings
stainless steel 316Ti adapter fittings
ASTM A182 F 316Ti instrumentation tube fittings
UNS S31635 gaugeable tube fittings
SUS 316Ti tube connectors
AISI 316Ti npt tube fittings
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 316TI | min. | – | – | – | – | – | 16.0 | 2.0-3.0 | 10.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | 0.1 | ||
Exporter of AISI 316Ti npt tube fittings and 316Ti instrumentation tube fittings, offering user-friendly installation and substantial labor savings.
| Grade | Tensile Strength (MPa) Minimum | Yield Strength (MPa) Minimum | Elongation (% in 50mm) Minimum | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316TI | 515 | 205 | 35 | 75 | 205 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 316TI | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
Find precise UNS S31635 gaugeable tube fittings and stainless steel 316Ti adapter fittings dimensions and sizes to meet your specific project demands
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
High-quality manufacturer of medium pressure 316Ti SS instrumentation fittings and DIN 1.4571 high pressure fittings
Application of DIN 1.4571 high pressure fittings
- Marine applications
- Brewing equipment
- Automotive manufacturing
- Aerospace industry
- Dairy equipment
Packaging of AISI 316Ti npt tube fittings
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What is the advantage of using stainless steel 316Ti instrumentation fittings compared to stainless steel 316 fittings?
Stainless steel 316Ti instrumentation fittings offer improved resistance to sensitization and intergranular corrosion at elevated temperatures.
Can AISI 316Ti npt tube fittings be used in chloride-rich environments?
Yes, AISI 316Ti npt tube fittings have excellent resistance to chloride-induced corrosion, making them suitable for chloride-rich environments.
Are SUS 316Ti tube connectors compatible with high-purity applications?
Yes, SUS 316Ti tube connectors are commonly used in high-purity applications due to their low carbon content and minimized impurities.
What is the temperature range in which ASTM A479 316Ti connectors can operate?
ASTM A479 316Ti connectors can typically withstand temperatures ranging from -50°C to 550°C (-58°F to 1022°F).
Are DIN 1.4571 high pressure fittings easy to install and maintain?
Yes, DIN 1.4571 high pressure fittings are designed for easy installation and maintenance, providing a reliable and convenient solution for various applications.
