Choose us as your SS 321H compression tee manufacturer in India
We offer Stainless Steel 321 Instrumentation Fittings in conventional and non-standard sizes, as well as a variety of specifications, forms, designations, and finishes. Our dedication to customer satisfaction motivates us to provide customized tube fittings that precisely fulfill the product needs of our customers. We secure the purchase of high-quality raw materials for our goods by maintaining a strong global sourcing network.
Fit-Lok understands that each project has its own set of requirements. As a result, we provide unique alternatives for our SS 321H compression tee. We collaborate closely with our customers to understand their individual requirements and provide customized solutions.
Learn about the hardness and thermal stability properties of our UNS S32100 compression fittings and SS 321 Bulkhead Union for precise applications.
Quality is of utmost importance to us at Fit-lok. To ensure that our UNS S32100 compression fittings meet the highest requirements, we employ extensive quality assurance methods throughout the manufacturing process. We obtain our raw materials from reputable sources all over the world, ensuring that our products are manufactured of high-quality materials that meet international standards.
Throughout the manufacturing process, we adhere to strict quality assurance methods to ensure that our AISI 321 Compression Tube Fittings satisfy the highest quality and reliability standards. To obtain high-quality raw materials for our DIN 1.4541 Female Elbow, we have a strong global sourcing network.
Table of content
- Stainless Steel 321 Instrumentation Tube Fittings Specification
- Types of UNS S32100 compression fittings
- SS 321 Bulkhead Union chemical composition
- AISI 321 Compression Tube Fittings mechanical composition
- DIN 1.4541 Female Elbow equivalent grade
- Size chart of Alloy 321 NPT Male Adapters
- Stainless Steel 321 BSPP Plugs Pressure rating
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
SS 321 Bulkhead Union
AISI 321 Compression Tube Fittings
DIN 1.4541 Female Elbow
Alloy 321 NPT Male Adapters
Stainless Steel 321 BSPP Plugs
UNS S32100 Front Ferrule
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
Our extensive range includes AISI 321 Compression Tube Fittings and DIN 1.4541 Female Elbow designed for both instrumentation and industrial applications.
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| SS 321H | 1.4878 | S32109 | SUS 321H | X12CrNiTi18-9 |
Precise dimensions and sizes for your Alloy 321 NPT Male Adapters and Stainless Steel 321 BSPP Plugs needs
| Tube OD (in) | Thread Size (in) | Hex Flat (in) |
|---|---|---|
| 1/16 | 1/16 | 0.31 |
| 1/8 | 1/8 | 0.38 |
| 3/16 | 1/8 | 0.38 |
| 1/4 | 1/4 | 0.46 |
| 5/16 | 1/4 | 0.46 |
| 3/8 | 3/8 | 0.54 |
| 1/2 | 1/2 | 0.71 |
| 5/8 | 1/2 | 0.71 |
| 3/4 | 3/4 | 0.83 |
| 7/8 | 3/4 | 0.83 |
| 1 | 1 | 1.02 |
| Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
| Male | Female | Female Swivel | Male | Female Swivel | ||||
| -02 | 1/8″ | 10000 | 5000 | 6000 | ||||
| -04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
| -05 | 5/16″ | 4250 | 8500 | 5000 | ||||
| -06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
| -08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
| -10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
| -12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
| -14 | 7/8″ | 2000 | 4000 | 3000 | ||||
| -16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
| -20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
| -24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
| -32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 | |
Efficient exporter of UNS S32100 Front Ferrule and 321 SS instrument fitting with easy installation and cost savings
Application of Stainless Steel 321 BSPP Plugs
- Food processing equipment
- Beverage industry
- Chemical processing
- Petrochemical industry
- Pharmaceutical equipment
Packaging of 321 SS instrument fitting
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What are the advantages of using stainless steel 321 instrumentation fittings in high-temperature applications?
Stainless steel 321 instrumentation fittings offer excellent oxidation resistance and thermal stability, making them suitable for high-temperature environments.
Are SS 321 BSPP Plugs resistant to sulfuric acid?
Yes, SS 321 BSPP Plugs exhibit good resistance to sulfuric acid, making them suitable for applications involving this corrosive chemical.
Can Alloy 321 NPT fittings be used in cryogenic conditions?
Yes, Alloy 321 NPT fittings maintain their mechanical properties and corrosion resistance at cryogenic temperatures, making them suitable for cryogenic applications.
Are 321 SS instrument fitting in different connection types?
Yes, 321 SS instrument fitting can be found in various connection types such as compression, NPT (National Pipe Thread), and butt-weld, offering flexibility for different installation requirements.
Do AISI 321 Compression Tube Fittings comply with international standards?
Yes, AISI 321 Compression Tube Fittings are manufactured in compliance with international standards such as ASTM and ASME, ensuring quality and performance consistency.
