One of the best UNS S34700 Male Run Tee manufacturer in India
Stainless Steel 347H Tube Fittings have strong resistance to intergranular corrosion and operate well even at high temperatures. Their resistance to chromium carbide precipitation, stress crack corrosion, and pitting makes them even more useful in harsh situations. SS 347H Bulkhead Union are a trustworthy solution for industries that require outstanding performance and longevity due to its strong creep and stress qualities.
We make certain that our UNS S34709 Male Run Tee has outstanding mechanical and chemical qualities. We send a sample of our product to an authorised laboratory for analysis. The received report is then kept on file as verification of our product and its quality. This uniquely developed and manufactured product has numerous uses in the aerospace sector, chemical processing industries, automotive, food industry, and waste management plants.
You can purchase Alloy 347H compression fittings and SS 347H Bulkhead Union from the supplier at reasonable prices.
Fit-lok maintains a record of all test reports and certificates. Before distribution, the final product that we make is subjected to stringent quality testing. We take extreme precautions during storage and shipping of AISI 347H Compression Tube Fittings. We pack our DIN 1.4961 Female Elbow in appropriate materials such as plastic bags or wooden boxes. It also protects the product from damage during storage and transit.
Before sending Alloy 347H NPT Male Adapters to our clients, we make certain that they have passed stringent quality checks. Fit-lok’s primary goal is to produce high-quality goods that meet the needs of our customers. For this goal, we generally adhere to international quality standards. In addition, to satisfy the urgent needs for large quantity products, we keep a stock of variable products in our well-equipped warehouse.
Table of content
- Stainless Steel 347H Instrumentation Tube Fittings Specification
- Types of UNS S34700 compression fittings
- SS 347H Bulkhead Union chemical composition
- AISI 347H Compression Tube Fittings mechanical composition
- DIN 1.4961 Female Elbow equivalent grade
- Size chart of UNS S34700 Front Ferrule
- 347H SS instrument fitting Pressure rating
Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
---|---|
Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
Ends | Threaded, Welding, JIC |
Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
Threads | NPT , BSPT, BSPP |
UNS S34700 compression fittings
SS 347H Bulkhead Union
AISI 347H Compression Tube Fittings
DIN 1.4961 Female Elbow
Alloy 347H NPT Male Adapters
Stainless Steel 347H BSPP Plugs
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
---|---|---|---|---|---|---|---|---|---|---|
347 | min. | – | – | – | – | – | 17.0 | – | 9.0 | – |
max. | 0.08 | 2.0 | 1.0 | 0.040 | 0.030 | 20.0 | 13.0 | – |
As a provider of AISI 347H Compression Tube Fittings and DIN 1.4961 Female Elbow, we cater to both instrumentation and industrial needs.
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
---|---|---|---|---|---|
Rockwell B (HR B) max | Brinell (HB) max | ||||
347 | 515 | 205 | 40 | 92 | 201 |
Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
---|---|---|---|---|---|---|---|---|---|
0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
347 | 8000 | 193 | 15.9 | 16.2 | 17.0 | 14.2 | 18.7 | 500 | 740 |
Wide range of Alloy 347H NPT Male Adapters and Stainless Steel 347H BSPP Plugs sizes and dimensions available
Tube OD (in) | Thread Size (in) | Hex Flat (in) |
---|---|---|
1/16 | 1/16 | 0.31 |
1/8 | 1/8 | 0.38 |
3/16 | 1/8 | 0.38 |
1/4 | 1/4 | 0.46 |
5/16 | 1/4 | 0.46 |
3/8 | 3/8 | 0.54 |
1/2 | 1/2 | 0.71 |
5/8 | 1/2 | 0.71 |
3/4 | 3/4 | 0.83 |
7/8 | 3/4 | 0.83 |
1 | 1 | 1.02 |
Dash Size | Nominal Tube/Pipe Size | SAE100R2 | National Pipe Tapered Fuel (NPTF) | National Pipe Straight Mechanical (NPSM) | JIC 37° Flare Hydraulic SAE J514 | Flareless Compression SAE J514 | ||
Male | Female | Female Swivel | Male | Female Swivel | ||||
-02 | 1/8″ | 10000 | 5000 | 6000 | ||||
-04 | 1/4″ | 5000 | 9500 | 4500 | 5000 | 8500 | 5500 | 6000 |
-05 | 5/16″ | 4250 | 8500 | 5000 | ||||
-06 | 3/8″ | 4000 | 8000 | 3500 | 4000 | 7000 | 4000 | 6000 |
-08 | 1/2″ | 3500 | 6000 | 3500 | 3500 | 6000 | 4000 | 6000 |
-10 | 5/8″ | 2750 | 5500 | 3000 | 5000 | |||
-12 | 3/4″ | 2250 | 5000 | 3000 | 3500 | 4000 | 3000 | 4500 |
-14 | 7/8″ | 2000 | 4000 | 3000 | ||||
-16 | 1″ | 2000 | 4000 | 2500 | 3000 | 3500 | 2500 | 4000 |
-20 | 1-1/4″ | 1625 | 3000 | 2000 | 2000 | 3500 | 2000 | |
-24 | 1-1/2″ | 1250 | 2000 | 1500 | 1500 | 2000 | 1500 | |
-32 | 2″ | 1125 | 2000 | 1400 | 1500 | 1250 | 1250 |
Exporter of UNS S34700 Front Ferrule and 347H SS instrument fitting with easy installation and 70% reduced labor costs
Application of UNS S34709 Male Run Tee
- Water treatment
- HVAC systems
- Automotive applications
- Aerospace industry
- Marine applications
Packaging of AISI 347H Compression Fittings
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What is the maximum operating temperature for stainless steel 347H instrumentation fittings?
Stainless steel 347H instrumentation fittings can typically operate at temperatures up to 1700°F (927°C) for prolonged periods.
Are UNS S34709 Male Run Tee suitable for high-pressure applications?
Yes, UNS S34709 Male Run Tee are designed to withstand high-pressure conditions, making them suitable for demanding industrial settings.
Can SS 347H Bulkhead Union be used in sour gas environments?
Yes, SS 347H Bulkhead Union exhibit good resistance to hydrogen sulfide (H2S) and are suitable for sour gas environments.
What are the common sizes available for Alloy 347H NPT Male Adapters?
Alloy 347H NPT Male Adapters are available in various sizes, including commonly used sizes such as 1/8″, 1/4″, 3/8″, 1/2″, 3/4″, and 1″ among others, catering to different installation requirements.
What is the difference between stainless steel 347 and 347H instrumentation fittings?
Stainless steel 347H instrumentation fittings have higher carbon content than 347 fittings, providing improved high-temperature strength and resistance to sensitization.
