One of the leading ASTM A249 Type 304 ERW Tubing Supplier in India
The Stainless Steel ERW Tube is constructed of various stainless steel materials and is created using the electric resistance welding technology. They are made by cold shaping a flat strip of steel into a rounded tube. It is subsequently pushed through various forming rollers, resulting in steel with multiple longitudinal seams. The tubes edges are simultaneously heated with high frequency electricity and squeezed to produce a bond.
The Stainless Steel Welded tube is constructed of any grade of stainless steel and produced using the welding process. Larger tubes for less essential purposes are primarily produced using this method, as they are prone to leakage at the welding joints. To prepare for the welding procedure, they might be shaped and bent.
Because of its economic feasibility, SS 304 ERW tube is commonly used in heat exchangers. These tubes are corrosion resistant and have a high tensile strength. The tubes are well-known for their adaptability and resistance to high temperatures. This is why SS 304 ERW tube is used in important applications such as petrochemical plants, power stations, chemical plants, and so on.The ASTM A249 Type 304 ERW Tubing is quite similar to the SA 249 Tp 304 Material, although their chemical makeup differs. SS 316 has a higher molybdenum concentration, which improves its corrosion resistance. As a result, these tubes are commonly employed in aquatic situations. They are long-lasting and sanitary.
Check Welded 304 Stainless Steel Tubing Dimensions & Weight charts
Choosing a good manufacturer is critical since it will help you obtain high-quality, dependable items. Some pointers for selecting the best Stainless Steel ERW tube Manufacturer or Supplier are as follows:
They should have been in the field for a long time, as an experienced manufacturer or supplier knows which items will work best for you.Choose a reliable manufacturer or supplier on whom you can rely for high-quality products.Ascertain that the producer uses high-quality materials in the production of a certain product.They must maintain dimensional precision while charging a competitive market price for the goods.They should have a large inventory and be able to deliver on schedule.
Table of content
- Specification List of Stainless Steel Welded Tube
- Different types of A249 Stainless Steel Pressure Tube
- Chemical composition of SS ERW Tube
- Mechanical properties of SS Welded Tube
- Equivalent grade of Stainless Steel Welded Tubing
- Wall Thickness Tolerance of ASTM A249 Type 304 ERW Tubing
- Dimensions of 304 Stainless Steel Tubing
Specification | ASTM A249/ ASME SA249 |
Surfaces | |
Standard length | 6 metres |
Delivery Condition | MF, Bright Annealed, Polished, Annealed and Pickled, Cold Drawn |
Thickness Range | Schedule 5 to Schedule XXS |
Manufacturing Type | CEW / Seamless / DOM / ERW / Fabricated / Welded / CDW / CDS / 100% X Ray Welded |
Surface Finish | BA, 500G, 2B, No.1, No.3, No.8, 800G Mirror finish, 8K, HL, No.4, 2D, Mirror Polished, 1D, 180G, 400G Satin/ Hairline, 320G, 400G, 600G |
Value Added Services |
|
END | Plain End, Beveled End, Treaded Tubes |
Processing Service | Welding, Decoiling, Bending, Punching, Cutting, Moulding |
Technique | Cold drawn, Cold rolled, Hot rolled, Extrusion Tubes |
Tolerance |
ASTM A249 Type 304 ERW Tubing
SA 249 Tp 304 Material
Welded 304 Stainless Steel Tubing
ASME SA 249 TP 304 Tube
ASTM A249 Welded SS Tubing
ASTM A249 304 Welded Tubing
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Ti | Fe | |
304 | min. | 18.0 | 8.0 | |||||||||
max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||||
304L | min. | 18.0 | 8.0 | |||||||||
max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 12.0 | 0.10 | ||||
304H | min. | 0.04 | 18.0 | 8.0 | ||||||||
max. | 0.010 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | |||||
SS 310 | 0.015 max | 2 max | 0.015 max | 0.020 max | 0.015 max | 24.00 26.00 | 0.10 max | 19.00 21.00 | 54.7 min | |||
SS 310S | 0.08 max | 2 max | 1.00 max | 0.045 max | 0.030 max | 24.00 26.00 | 0.75 max | 19.00 21.00 | 53.095 min | |||
SS 310H | 0.04 0.10 | 2 max | 1.00 max | 0.045 max | 0.030 max | 24.00 26.00 | 19.00 21.00 | 53.885 min | ||||
316 | min. | 16.0 | 2.03.0 | 10.0 | ||||||||
max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | |||||
316L | min. | 16.0 | 2.03.0 | 10.0 | ||||||||
max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | |||||
316TI | 0.08 max | 10.00 14.00 | 2.0 max | 0.045 max | 0.030 max | 16.00 18.00 | 0.75 max | 2.00 3.00 | ||||
317 | 0.08 max | 2 max | 1 max | 0.045 max | 0.030 max | 18.00 20.00 | 3.00 4.00 | 57.845 min | ||||
SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 20.00 | 3.00 4.00 | 11.00 15.00 | 57.89 min | |||
SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 19.00 | 9.00 12.00 | 0.10 max | 5(C+N) 0.70 max | |||
SS 321H | 0.04 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 19.00 | 9.00 12.00 | 0.10 max | 4(C+N) 0.70 max | |||
347/ 347H | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 20.00 | 9.0013.00 | |||||
410 | min. | 11.5 | ||||||||||
max. | 0.15 | 1.0 | 1.00 | 0.040 | 0.030 | 13.5 | 0.75 | |||||
446 | min. | 23.0 | 0.10 | |||||||||
max. | 0.2 | 1.5 | 0.75 | 0.040 | 0.030 | 30.0 | 0.50 | 0.25 | ||||
904L | min. | 19.0 | 4.00 | 23.00 | 0.10 | |||||||
max. | 0.20 | 2.00 | 1.00 | 0.045 | 0.035 | 23.0 | 5.00 | 28.00 | 0.25 |
ASME SA 249 TP 304 Tube is available in a thickness range that includes Schedule 5 through Schedule XXS.
Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
304/ 304L | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
304H | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 40 % |
310 / 310S / 310H | 7.9 g/cm3 | 1402 °C (2555 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 40 % |
306/ 316H | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
316L | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
317 | 7.9 g/cm3 | 1400 °C (2550 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
321 | 8.0 g/cm3 | 1457 °C (2650 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
347 | 8.0 g/cm3 | 1454 °C (2650 °F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
904L | 7.95 g/cm3 | 1350 °C (2460 °F) | Psi 71000 , MPa 490 | Psi 32000 , MPa 220 | 35 % |
Accept all small/ Large Orders for ASTM A249 Welded SS Tubing, Check ASTM A249 304 Welded Tubing Price Per Kg
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
SS 304H | 1.4301 | S30409 | – | – | – | – | – |
SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
SS 310H | – | S31009 | – | – | – | – | – |
SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
SS 316H | 1.4401 | S31609 | – | – | – | – | – |
SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
SS 317 | 1.4449 | S31700 | SUS 317 | – | – | – | – |
SS 317L | 1.4438 | S31703 | SUS 317L | – | – | – | X2CrNiMo18-15-4 |
SS 321 | 1.4541 | S32100 | SUS 321 | – | – | – | X6CrNiTi18-10 |
SS 321H | 1.4878 | S32109 | SUS 321H | – | – | – | X12CrNiTi18-9 |
SS 347 | 1.4550 | S34700 | SUS 347 | – | 08Ch18N12B | – | X6CrNiNb18-10 |
SS 347H | 1.4961 | S34709 | SUS 347H | – | – | – | X6CrNiNb18-12 |
SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
NPS | Tolerance, % | |
+ | – | |
1/8-2 1 /2 | 20.0 | 12.5 |
3~18, t/D≤ 5% | 22.5 | 12.5 |
3~18, t/D> 5% | 15.0 | 12.5 |
≥ 20, welded | 17.5 | 12.5 |
≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
Looking to Buy Sa-249 Welded Tubing from Suppliers, Ask For ready stock of ASTM A249 Type 304 ERW Tubing
OD inches | Ave. Wall inches | D/t Ratio | ID inches | Tube Cross Sectional Area (in2) | Internal Area (in2) |
---|---|---|---|---|---|
0.250 | 0.020 | 12.50 | 0.210 | 0.0145 | 0.0346 |
0.250 | 0.028 | 8.93 | 0.194 | 0.0195 | 0.0296 |
0.250 | 0.035 | 7.14 | 0.180 | 0.0236 | 0.0254 |
0.250 | 0.049 | 5.10 | 0.152 | 0.0309 | 0.0181 |
0.250 | 0.065 | 3.85 | 0.120 | 0.0378 | 0.0113 |
0.375 | 0.020 | 18.75 | 0.335 | 0.0223 | 0.0881 |
0.375 | 0.028 | 13.39 | 0.319 | 0.0305 | 0.0799 |
0.375 | 0.035 | 10.71 | 0.305 | 0.0374 | 0.0731 |
0.375 | 0.049 | 7.65 | 0.277 | 0.0502 | 0.0603 |
0.375 | 0.065 | 5.77 | 0.245 | 0.0633 | 0.0471 |
0.500 | 0.020 | 25.00 | 0.460 | 0.0302 | 0.1662 |
0.500 | 0.028 | 17.86 | 0.444 | 0.0415 | 0.1548 |
0.500 | 0.035 | 14.29 | 0.430 | 0.0511 | 0.1452 |
0.500 | 0.049 | 10.20 | 0.402 | 0.0694 | 0.1269 |
0.500 | 0.065 | 7.69 | 0.370 | 0.0888 | 0.1075 |
0.500 | 0.083 | 6.02 | 0.334 | 0.1087 | 0.0876 |
0.625 | 0.020 | 31.25 | 0.585 | 0.0380 | 0.2688 |
0.625 | 0.028 | 22.32 | 0.569 | 0.0525 | 0.2543 |
0.625 | 0.035 | 17.86 | 0.555 | 0.0649 | 0.2419 |
0.625 | 0.049 | 12.76 | 0.527 | 0.0887 | 0.2181 |
0.625 | 0.065 | 9.62 | 0.495 | 0.1144 | 0.1924 |
0.625 | 0.083 | 7.53 | 0.459 | 0.1413 | 0.1655 |
0.625 | 0.095 | 6.58 | 0.435 | 0.1582 | 0.1486 |
0.625 | 0.109 | 5.73 | 0.407 | 0.1767 | 0.1301 |
0.750 | 0.028 | 26.79 | 0.694 | 0.0635 | 0.3783 |
0.750 | 0.035 | 21.43 | 0.680 | 0.0786 | 0.3632 |
0.750 | 0.049 | 15.31 | 0.652 | 0.1079 | 0.3339 |
0.750 | 0.065 | 11.54 | 0.620 | 0.1399 | 0.3019 |
0.750 | 0.083 | 9.04 | 0.584 | 0.1739 | 0.2679 |
0.750 | 0.095 | 7.89 | 0.560 | 0.1955 | 0.2463 |
0.750 | 0.109 | 6.88 | 0.532 | 0.2195 | 0.2223 |
0.750 | 0.120 | 6.25 | 0.510 | 0.2375 | 0.2043 |
0.875 | 0.020 | 43.75 | 0.835 | 0.0537 | 0.5476 |
0.875 | 0.028 | 31.25 | 0.819 | 0.0745 | 0.5268 |
0.875 | 0.035 | 25.00 | 0.805 | 0.0924 | 0.5090 |
0.875 | 0.049 | 17.86 | 0.777 | 0.1272 | 0.4742 |
0.875 | 0.065 | 13.46 | 0.745 | 0.1654 | 0.4359 |
0.875 | 0.083 | 10.54 | 0.709 | 0.2065 | 0.3948 |
0.875 | 0.095 | 9.21 | 0.685 | 0.2328 | 0.3685 |
0.875 | 0.109 | 8.03 | 0.657 | 0.2623 | 0.3390 |
0.875 | 0.120 | 7.29 | 0.635 | 0.2846 | 0.3167 |
1.000 | 0.028 | 35.71 | 0.944 | 0.0855 | 0.6999 |
1.000 | 0.035 | 28.57 | 0.930 | 0.1061 | 0.6793 |
1.000 | 0.049 | 20.41 | 0.902 | 0.1464 | 0.6390 |
1.000 | 0.065 | 15.38 | 0.870 | 0.1909 | 0.5945 |
1.000 | 0.083 | 12.05 | 0.834 | 0.2391 | 0.5463 |
1.000 | 0.095 | 10.53 | 0.810 | 0.2701 | 0.5153 |
1.000 | 0.109 | 9.17 | 0.782 | 0.3051 | 0.4803 |
1.000 | 0.120 | 8.33 | 0.760 | 0.3318 | 0.4536 |
1.000 | 0.134 | 7.46 | 0.732 | 0.3646 | 0.4208 |
1.250 | 0.035 | 35.71 | 1.180 | 0.1336 | 1.0936 |
1.250 | 0.049 | 25.51 | 1.152 | 0.1849 | 1.0423 |
1.250 | 0.065 | 19.23 | 1.120 | 0.2420 | 0.9852 |
1.250 | 0.083 | 15.06 | 1.084 | 0.3043 | 0.9229 |
1.250 | 0.095 | 13.16 | 1.060 | 0.3447 | 0.8825 |
1.250 | 0.109 | 11.47 | 1.032 | 0.3907 | 0.8365 |
1.250 | 0.120 | 10.42 | 1.010 | 0.4260 | 0.8012 |
1.250 | 0.134 | 9.33 | 0.982 | 0.4698 | 0.7574 |
1.500 | 0.035 | 42.86 | 1.430 | 0.1611 | 1.6061 |
1.500 | 0.049 | 30.61 | 1.402 | 0.2234 | 1.5438 |
1.500 | 0.065 | 23.08 | 1.370 | 0.2930 | 1.4741 |
1.500 | 0.083 | 18.07 | 1.334 | 0.3695 | 1.3977 |
1.500 | 0.095 | 15.79 | 1.310 | 0.4193 | 1.3478 |
1.500 | 0.109 | 13.76 | 1.282 | 0.4763 | 1.2908 |
1.500 | 0.120 | 12.50 | 1.260 | 0.5202 | 1.2469 |
1.500 | 0.134 | 11.19 | 1.232 | 0.5750 | 1.1921 |
1.500 | 0.148 | 10.14 | 1.204 | 0.6286 | 1.1385 |
1.750 | 0.035 | 50.00 | 1.680 | 0.1886 | 2.2167 |
1.750 | 0.049 | 40.82 | 1.902 | 0.3003 | 2.8413 |
1.750 | 0.065 | 26.92 | 1.620 | 0.3441 | 2.0612 |
1.750 | 0.083 | 21.08 | 1.584 | 0.4347 | 1.9706 |
1.750 | 0.095 | 18.42 | 1.560 | 0.4939 | 1.9113 |
1.750 | 0.109 | 16.06 | 1.532 | 0.5619 | 1.8433 |
1.750 | 0.120 | 14.58 | 1.510 | 0.6145 | 1.7908 |
1.750 | 0.134 | 13.06 | 1.482 | 0.6803 | 1.7250 |
1.750 | 0.148 | 11.82 | 1.454 | 0.7449 | 1.6604 |
1.750 | 0.165 | 10.61 | 1.420 | 0.8216 | 1.5837 |
2.000 | 0.035 | 57.14 | 1.930 | 0.2161 | 2.9255 |
2.000 | 0.049 | 40.82 | 1.902 | 0.3003 | 2.8413 |
2.000 | 0.065 | 30.77 | 1.870 | 0.3951 | 2.7465 |
2.000 | 0.083 | 24.10 | 1.834 | 0.4999 | 2.6417 |
2.000 | 0.095 | 21.05 | 1.810 | 0.5685 | 2.5730 |
2.000 | 0.109 | 18.35 | 1.782 | 0.6475 | 2.4941 |
2.000 | 0.120 | 16.67 | 1.760 | 0.7087 | 2.4328 |
2.000 | 0.134 | 14.93 | 1.732 | 0.7855 | 2.3561 |
2.000 | 0.148 | 13.51 | 1.704 | 0.8611 | 2.2805 |
2.000 | 0.165 | 12.12 | 1.670 | 0.9512 | 2.1904 |
Application of SS welded tube
- Aerospace industry
- Dairy equipment
- Marine applications
- Automotive manufacturing
- Brewing equipment
Packaging of Stainless steel ERW tubing
Keep fragile items protected by encasing them in plastic or paper sleeves within bundles. Opt for wooden crates to protect and preserve your goods during long-distance shipping. Cardboard boxes offer cost-effective and recyclable packaging solutions for various items.
