We are leading Manufacturer of Stainless steel Ball Joint Union in Mumbai
A union joint ball, also known as a ball joint union, is a form of pipe fitting that allows two pipes to swivel together. It is made out of a ball-shaped segment with male and female threads on one end. The ball joint enables fluid systems to adapt to varied angles and accommodate potential movement or vibration. Union joint balls are available in a variety of sizes and materials to fit various pipe types and fluid system requirements.
We are leading stockist and supplier of Ball Joint Union
A union joint ball’s principal function is to allow swivel couplings between two pipes. The fitting allows rotational movement by including a ball joint, making it easy to alter the angle of the connected pipes. This flexibility is especially advantageous in fluid systems when movement or alignment adjustments are required, as it reduces piping stress and improves overall system performance.
Table of content
| Types | NPT, ISO/BP, SAE/MS, AN, weld ends |
| Size | 1/16 to 2 in.; 2 to 50 mm, Medium-Pressure – 1/4, 3/8, 1/2, 9/16, 3/4, 1 in.; 6, 10, 12 mm, High-Pressure – 1/8 to 9/16 in. |
| Pressure Ratings | Up to 11 000 psig (760 bar), Medium-Pressure – Up to 20 000 psig (1378 bar), High-Pressure – Up to 60 000 psig (4134 bar). |
| Temperature Ratings | Up to 1000°F (537°C) |
| Thread | Thread BSPT, UNF, NPT, BSP, |
Stainless steel Union Ball Joint
Ball Joint Union
Union Ball Joint 3/4 NPTF
| Stainless Steel | ASTM / ASME 201, 202, 301, 304, 304L, 310, 310S, 316L, 316TI, 317, 317L, 321, 347, 409, 409M, 409L, 410, 410S, 420, 430, 431, 441, 444, 446, 17.4PH, 904L |
| Super Duplex Steel | S32750 |
| Carbon Steel | ASTM / ASME A 335 GRP 1 , P 5 , P 9 , P 11 , P 12 , P 22 , P 23 , P 91 |
| Duplex Steel | ASTM / ASME SA 790 UNS NO S 31803 , S 32205 , S 32550 , S 32750 , S 32760. |
| Alloys Steel | ASTM / ASME A 691 GRP1 CR , 1 1/4 CR , 2 1/4 CR , 5 CR , 9CR , 91. |
| Titanium | Grade 1, Grade 4, Grade 5(Ti 6Al-4V), Grade 6(Ti 5Al-2.5Sn), Grade 7, Grade 11, Grade 12, 8Ai-1Mo-1V, Grade 9(3Al-2.5V), 6Al-6V-25n, 6Al-2Sn-4Zr-2Mo, 6Al-7Nb, Grade 23(Ti 6AL-4V ELI), Grade 5 ELI |
| Hastelloy | Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000, Hastelloy C-4, Hastelloy X, Hastelloy B, Hastelloy N, Hastelloy G |
| Nickel Alloys | Nickel Alloys 200, Nickel Alloys 201 |
| Inconel | Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750 , Inconel 690, Inconel 602, Inconel 617, Inconel 925, Inconel A-289, Inconel AL-6XN, AL-904L |
- Power generation
- Industrial machinery
- Brewing equipment
- Construction and architecture
- Textile industry
- Pitting Resistance Test
- Micro and Macro Test
- Hardness Test
- Flaring Test
- IGC Test
- Flattening Test
- Chemical Analysis
Packaging of Union Joint Ball
- Plastic or Paper Sleeves
- Wooden Crates
- Cardboard Boxes
- Palletizing
- Strapping
Frequently asked questions
What is a Union Joint Ball, and how is it used in pipe connections?
A Union Joint Ball is a type of pipe fitting that provides a swivel connection between two pipes, allowing for easy adjustment and movement.
What are the common sizes and materials available for Union Joint Balls?
Union Joint Balls are available in various common sizes and materials such as brass, stainless steel, or PVC, offering compatibility with different pipe sizes and durability in various applications.
What are the advantages and applications of using Union Joint Balls in plumbing or mechanical systems?
The advantages of using Union Joint Balls include their ability to provide flexible connections, accommodate angular misalignment, and facilitate easy installation or disassembly in plumbing, irrigation, or mechanical systems.
